396-3815Y1 SureFire PumpRight for Raven RCM 15 Revised 01/16/2018
Colored Disc Orifice Chart
15” Spacing 15” Spacing 15” Spacing
PSI 4.0 4.5 5.0 5.5 6.0 6.5 7.0
10 0.033 3.2 2.9 2.6 2.4 2.2 2.0 1.9
20 0.046 4.6 4.0 3.6 3.3 3.0 2.8 2.6
30 0.057 5.6 5.0 4.5 4.1 3.7 3.5 3.2
40 0.065 6.5 5.8 5.2 4.7 4.3 4.0 3.7
50 0.073 7.3 6.5 5.8 5.3 4.8 4.5 4.2
60 0.081 8.0 7.1 6.4 5.8 5.3 4.9 4.6
10 0.050 5.0 4.4 4.0 3.6 3.3 3.1 2.9
20 0.072 7.1 6.3 5.7 5.2 4.7 4.4 4.1
30 0.088 8.7 7.7 6.9 6.3 5.8 5.3 5.0
40 0.101 10.0 8.9 8.0 7.3 6.7 6.1 5.7
50 0.112 11.1 9.9 8.9 8.1 7.4 6.8 6.4
60 0.124 12.3 10.9 9.8 8.9 8.2 7.5 7.0
10 0.070 6.9 6.2 5.5 5.0 4.6 4.3 4.0
20 0.098 9.7 8.6 7.8 7.1 6.5 6.0 5.6
30 0.120 11.9 10.6 9.5 8.7 7.9 7.3 6.8
40 0.139 13.8 12.2 11.0 10.0 9.2 8.5 7.9
50 0.156 15.4 13.7 12.3 11.2 10.3 9.5 8.8
60 0.170 16.8 15.0 13.5 12.2 11.2 10.4 9.6
10 0.094 9.3 8.3 7.4 6.8 6.2 5.7 5.3
20 0.132 13.1 11.6 10.4 9.5 8.7 8.0 7.5
30 0.162 16.0 14.3 12.8 11.7 10.7 9.9 9.2
40 0.187 18.5 16.4 14.8 13.4 12.3 11.4 10.6
50 0.209 20.7 18.4 16.5 15.0 13.8 12.7 11.8
60 0.228 22.6 20.1 18.1 16.4 15.1 13.9 12.9
10 0.119 11.8 10.5 9.5 8.6 7.9 7.3 6.8
20 0.169 16.7 14.9 13.4 12.2 11.2 10.3 9.6
30 0.207 20.5 18.2 16.4 14.9 13.7 12.6 11.7
40 0.239 23.7 21.0 18.9 17.2 15.8 14.6 13.5
50 0.267 26.5 23.5 21.2 19.2 17.6 16.3 15.1
60 0.293 29.0 25.8 23.2 21.1 19.3 17.8 16.6
10 0.149 15 13 12 11 10 9 8
20 0.210 21 18 17 15 14 13 12
30 0.257 25 23 20 18 17 16 15
40 0.296 29 26 23 21 20 18 17
50 0.332 33 29 26 24 22 20 19
60 0.363 36 32 29 26 24 22 21
10 0.218 22 19 17 16 14 13 12
20 0.307 30 27 24 22 20 19 17
30 0.376 37 33 30 27 25 23 21
40 0.435 43 38 34 31 29 26 25
50 0.486 48 43 38 35 32 30 27
60 0.532 53 47 42 38 35 32 30
10 0.351 35 31 28 25 23 21 20
20 0.496 49 44 39 36 33 30 28
30 0.608 60 54 48 44 40 37 34
40 0.702 69 62 56 51 46 43 40
50 0.785 78 69 62 57 52 48 44
60 0.859 85 76 68 62 57 52 49
10 0.506 50 45 40 36 33 31 29
20 0.715 71 63 57 51 47 44 40
30 0.876 87 77 69 63 58 53 50
40 1.009 100 89 80 73 67 61 57
50 1.133 112 100 90 82 75 69 64
60 1.239 123 109 98 89 82 75 70
10 0.686 68 60 54 49 45 42 39
20 0.973 96 86 77 70 64 59 55
30 1.186 117 104 94 85 78 72 67
40 1.372 136 121 109 99 91 84 78
50 1.531 152 135 121 110 101 93 87
60 1.681 166 148 133 121 111 102 95
10 0.867 86 76 69 62 57 53 49
20 1.230 122 108 97 89 81 75 70
30 1.504 149 132 119 108 99 92 85
40 1.735 172 153 137 125 114 106 98
50 1.938 192 171 153 140 128 118 110
60 2.124 210 187 168 153 140 129 120
10 1.372 136 121 109 99 91 84 78
20 1.947 193 171 154 140 128 119 110
30 2.381 236 209 189 171 157 145 135
40 2.752 272 242 218 198 182 168 156
50 3.071 304 270 243 221 203 187 174
60 3.363 333 296 266 242 222 205 190
All application rates (gallons/acres) are estimates based on 0-28-0 (10.65 lbs/gallon) at 70 degrees F.
Orifice
Color
(Approx
Size)
PSI 4.0 4.5 5.0 5.5 6.0 6.5 7.0
10 0.033 2.4 2.2 1.9 1.8 1.6 1.5 1.4
20 0.046 3.4 3.0 2.7 2.5 2.3 2.1 2.0
30 0.057 4.2 3.7 3.4 3.1 2.8 2.6 2.4
40 0.065 4.9 4.3 3.9 3.5 3.2 3.0 2.8
50 0.073 5.5 4.8 4.4 4.0 3.6 3.4 3.1
60 0.081 6.0 5.3 4.8 4.3 4.0 3.7 3.4
10 0.050 3.7 3.3 3.0 2.7 2.5 2.3 2.1
20 0.072 5.3 4.7 4.3 3.9 3.5 3.3 3.0
30 0.088 6.5 5.8 5.2 4.7 4.3 4.0 3.7
40 0.101 7.5 6.7 6.0 5.4 5.0 4.6 4.3
50 0.112 8.3 7.4 6.7 6.1 5.6 5.1 4.8
60 0.124 9.2 8.2 7.4 6.7 6.1 5.7 5.3
10 0.070 5.2 4.6 4.2 3.8 3.5 3.2 3.0
20 0.098 7.3 6.5 5.8 5.3 4.9 4.5 4.2
30 0.120 8.9 7.9 7.1 6.5 6.0 5.5 5.1
40 0.139 10.3 9.2 8.3 7.5 6.9 6.3 5.9
50 0.156 11.6 10.3 9.3 8.4 7.7 7.1 6.6
60 0.170 12.6 11.2 10.1 9.2 8.4 7.8 7.2
10 0.094 7.0 6.2 5.6 5.1 4.6 4.3 4.0
20 0.132 9.8 8.7 7.8 7.1 6.5 6.0 5.6
30 0.162 12.0 10.7 9.6 8.7 8.0 7.4 6.9
40 0.187 13.9 12.3 11.1 10.1 9.2 8.5 7.9
50 0.209 15.5 13.8 12.4 11.3 10.3 9.5 8.9
60 0.228 17.0 15.1 13.6 12.3 11.3 10.4 9.7
10 0.119 8.9 7.9 7.1 6.5 5.9 5.5 5.1
20 0.169 12.6 11.2 10.0 9.1 8.4 7.7 7.2
30 0.207 15.4 13.7 12.3 11.2 10.3 9.5 8.8
40 0.239 17.7 15.8 14.2 12.9 11.8 10.9 10.1
50 0.267 19.8 17.6 15.9 14.4 13.2 12.2 11.3
60 0.293 21.7 19.3 17.4 15.8 14.5 13.4 12.4
10 0.149 11 10 9 8 7 7 6
20 0.210 16 14 12 11 10 10 9
30 0.257 19 17 15 14 13 12 11
40 0.296 22 20 18 16 15 14 13
50 0.332 25 22 20 18 16 15 14
60 0.363 27 24 22 20 18 17 15
10 0.218 16 14 13 12 11 10 9
20 0.307 23 20 18 17 15 14 13
30 0.376 28 25 22 20 19 17 16
40 0.435 32 29 26 23 22 20 18
50 0.486 36 32 29 26 24 22 21
60 0.532 39 35 32 29 26 24 23
10 0.351 26 23 21 19 17 16 15
20 0.496 37 33 29 27 25 23 21
30 0.608 45 40 36 33 30 28 26
40 0.702 52 46 42 38 35 32 30
50 0.785 58 52 47 42 39 36 33
60 0.859 64 57 51 46 43 39 36
10 0.506 38 33 30 27 25 23 21
20 0.715 53 47 42 39 35 33 30
30 0.876 65 58 52 47 43 40 37
40 1.009 75 67 60 54 50 46 43
50 1.133 84 75 67 61 56 52 48
60 1.239 92 82 74 67 61 57 53
10 0.686 51 45 41 37 34 31 29
20 0.973 72 64 58 53 48 44 41
30 1.186 88 78 70 64 59 54 50
40 1.372 102 91 81 74 68 63 58
50 1.531 114 101 91 83 76 70 65
60 1.681 125 111 100 91 83 77 71
10 0.867 64 57 52 47 43 40 37
20 1.230 91 81 73 66 61 56 52
30 1.504 112 99 89 81 74 69 64
40 1.735 129 114 103 94 86 79 74
50 1.938 144 128 115 105 96 89 82
60 2.124 158 140 126 115 105 97 90
10 1.372 102 91 81 74 68 63 58
20 1.947 145 128 116 105 96 89 83
30 2.381 177 157 141 129 118 109 101
40 2.752 204 182 163 149 136 126 117
50 3.071 228 203 182 166 152 140 130
60 3.363 250 222 200 182 166 154 143
All application rates (gallons/acres) are estimates based on 0-28-0 (10.65 lbs/gallon) at 70 degrees F.
Orifice
Color
(Approx
Size)
20” Spacing 20” Spacing 20” Spacing
