396-3815Y1 SureFire PumpRight for Raven RCM 14 Revised 01/16/2018
Colored Disc Orifice Chart
Common Grain Drill Row Spacings
B
Components
Liquid
7.5” Spacing
PSI 4.0 4.5 5.0 5.5 6.0 6.5 7.0
10 0.033 6.5 5.8 5.2 4.7 4.3 4.0 3.7
20 0.046 9.1 8.1 7.3 6.6 6.1 5.6 5.2
30 0.057 11.2 10.0 9.0 8.2 7.5 6.9 6.4
40 0.065 13.0 11.5 10.4 9.4 8.6 8.0 7.4
50 0.073 14.5 12.9 11.6 10.6 9.7 8.9 8.3
60 0.081 15.9 14.2 12.8 11.6 10.6 9.8 9.1
10 0.050 10.0 8.9 8.0 7.3 6.7 6.1 5.7
20 0.072 14.2 12.6 11.4 10.3 9.5 8.7 8.1
30 0.088 17.3 15.4 13.9 12.6 11.6 10.7 9.9
40 0.101 20.0 17.8 16.0 14.5 13.3 12.3 11.4
50 0.112 22.3 19.8 17.8 16.2 14.8 13.7 12.7
60 0.124 24.5 21.8 19.6 17.8 16.4 15.1 14.0
10 0.070 13.8 12.3 11.1 10.1 9.2 8.5 7.9
20 0.098 19.4 17.3 15.6 14.1 13.0 12.0 11.1
30 0.120 23.8 21.2 19.1 17.3 15.9 14.7 13.6
40 0.139 27.5 24.5 22.0 20.0 18.3 16.9 15.7
50 0.156 30.8 27.4 24.7 22.4 20.6 19.0 17.6
60 0.170 33.6 29.9 26.9 24.5 22.4 20.7 19.2
10 0.094 19 17 15 14 12 11 11
20 0.132 26 23 21 19 17 16 15
30 0.162 32 29 26 23 21 20 18
40 0.187 37 33 30 27 25 23 21
50 0.209 41 37 33 30 28 25 24
60 0.228 45 40 36 33 30 28 26
10 0.119 24 21 19 17 16 15 14
20 0.169 33 30 27 24 22 21 19
30 0.207 41 36 33 30 27 25 23
40 0.239 47 42 38 34 32 29 27
50 0.267 53 47 42 38 35 33 30
60 0.293 58 52 46 42 39 36 33
10 0.149 29 26 24 21 20 18 17
20 0.210 42 37 33 30 28 26 24
30 0.257 51 45 41 37 34 31 29
40 0.296 59 52 47 43 39 36 34
50 0.332 66 58 53 48 44 40 38
60 0.363 72 64 57 52 48 44 41
10 0.218 43 38 34 31 29 27 25
20 0.307 61 54 49 44 41 37 35
30 0.376 74 66 60 54 50 46 43
40 0.435 86 76 69 63 57 53 49
50 0.486 96 86 77 70 64 59 55
60 0.532 105 94 84 77 70 65 60
10 0.351 70 62 56 51 46 43 40
20 0.496 98 87 79 71 66 60 56
30 0.608 120 107 96 88 80 74 69
40 0.702 139 124 111 101 93 86 79
50 0.785 155 138 124 113 104 96 89
60 0.859 170 151 136 124 113 105 97
10 0.506 100 89 80 73 67 62 57
20 0.715 142 126 113 103 94 87 81
30 0.876 173 154 139 126 116 107 99
40 1.009 200 178 160 145 133 123 114
50 1.133 224 199 179 163 150 138 128
60 1.239 245 218 196 178 164 151 140
All application rates (gallons/acres) are estimates based on 0-28-0 (10.65 lbs/gallon) at 70 degrees F.
Brown
(41)
Orange
(46)
Maroon
(52)
Red (63)
Blue (80)
Yellow
(95)
MPH
Pink (24)
Gray (30)
Black (35)
Gal/Min
28-0-0
Orifice
Color
(Approx
Size)
PSI 4.0 4.5 5.0 5.5 6.0 6.5 7.0
10 0.033 4.9 4.3 3.9 3.5 3.2 3.0 2.8
20 0.046 6.8 6.1 5.5 5.0 4.6 4.2 3.9
30 0.057 8.4 7.5 6.7 6.1 5.6 5.2 4.8
40 0.065 9.7 8.6 7.8 7.1 6.5 6.0 5.6
50 0.073 10.9 9.7 8.7 7.9 7.3 6.7 6.2
60 0.081 12.0 10.6 9.6 8.7 8.0 7.4 6.8
10 0.050 7.5 6.7 6.0 5.4 5.0 4.6 4.3
20 0.072 10.6 9.5 8.5 7.7 7.1 6.6 6.1
30 0.088 13.0 11.6 10.4 9.5 8.7 8.0 7.4
40 0.101 15.0 13.3 12.0 10.9 10.0 9.2 8.6
50 0.112 16.7 14.8 13.4 12.1 11.1 10.3 9.5
60 0.124 18.4 16.4 14.7 13.4 12.3 11.3 10.5
10 0.070 10.4 9.2 8.3 7.6 6.9 6.4 5.9
20 0.098 14.6 13.0 11.7 10.6 9.7 9.0 8.3
30 0.120 17.9 15.9 14.3 13.0 11.9 11.0 10.2
40 0.139 20.6 18.3 16.5 15.0 13.8 12.7 11.8
50 0.156 23.1 20.6 18.5 16.8 15.4 14.2 13.2
60 0.170 25.2 22.4 20.2 18.4 16.8 15.5 14.4
10 0.094 14 12 11 10 9 9 8
20 0.132 20 17 16 14 13 12 11
30 0.162 24 21 19 17 16 15 14
40 0.187 28 25 22 20 18 17 16
50 0.209 31 28 25 23 21 19 18
60 0.228 34 30 27 25 23 21 19
10 0.119 18 16 14 13 12 11 10
20 0.169 25 22 20 18 17 15 14
30 0.207 31 27 25 22 21 19 18
40 0.239 35 32 28 26 24 22 20
50 0.267 40 35 32 29 26 24 23
60 0.293 43 39 35 32 29 27 25
10 0.149 22 20 18 16 15 14 13
20 0.210 31 28 25 23 21 19 18
30 0.257 38 34 30 28 25 23 22
40 0.296 44 39 35 32 29 27 25
50 0.332 49 44 39 36 33 30 28
60 0.363 54 48 43 39 36 33 31
10 0.218 32 29 26 24 22 20 18
20 0.307 46 41 36 33 30 28 26
30 0.376 56 50 45 41 37 34 32
40 0.435 65 57 52 47 43 40 37
50 0.486 72 64 58 52 48 44 41
60 0.532 79 70 63 57 53 49 45
10 0.351 52 46 42 38 35 32 30
20 0.496 74 66 59 54 49 45 42
30 0.608 90 80 72 66 60 56 52
40 0.702 104 93 83 76 69 64 60
50 0.785 117 104 93 85 78 72 67
60 0.859 128 113 102 93 85 79 73
10 0.506 75 67 60 55 50 46 43
20 0.715 106 94 85 77 71 65 61
30 0.876 130 116 104 95 87 80 74
40 1.009 150 133 120 109 100 92 86
50 1.133 168 150 135 122 112 104 96
60 1.239 184 164 147 134 123 113 105
All application rates (gallons/acres) are estimates based on 0-28-0 (10.65 lbs/gallon) at 70 degrees F.
Brown
(41)
Orange
(46)
Maroon
(52)
Red (63)
Blue (80)
Yellow
(95)
MPH
Pink (24)
Gray (30)
Black (35)
Gal/Min
28-0-0
Orifice
Color
(Approx
Size)
10” Spacing
7.5” Spacing 7.5” Spacing 7.5” Spacing 7.5” Spacing
