7-12 SERVICING INFORMATION
CABLE ROUTING
Front brake cable
Front brake cable
Clamp
Clamp
Wire harness
Face
the circlip end
down.
Clutch cable
Clutch cable
Throttle cable
Steering stem upper bracket
