4-2 FUEL AND LUBRICATION SYSTEM
FUEL TANK
REMOVAL
Remove the seat and side covers. ( 6-2)
Turn the fuel valve to the “OFF” position.
Disconnect the fuel hose.
Gasoline is highly flammable and explosive.
Keep heat, sparks, and flames away from gasoline.
Remove the fuel tank.
REMOUNTING
Remount the fuel tank in the reverse order of removal.

Suzuki DR-Z400S 2001 Specifications

General

Bore x Stroke	90.0 mm x 62.6 mm
Compression Ratio	11.3:1
Ignition	Electronic ignition (CDI)
Transmission	5-speed constant mesh
Final Drive	Chain
Front Suspension	Telescopic, coil spring, oil damped
Rear Suspension	Link type, coil spring, oil damped
Front Tire	80/100-21
Rear Tire	120/90-18
Seat Height	935 mm (36.8 in)
Engine Type	398cc, 4-stroke, liquid-cooled, DOHC
Front Brakes	Single hydraulic disc
Rear Brakes	Single hydraulic disc
Ground Clearance	300 mm (11.8 in.)
Wheelbase	1, 485 mm (58.5 in)
Fuel Tank Capacity	10.0 L (2.6 US gal.)
Fuel System	Mikuni BSR36, single carburetor
