Suzuki DR-Z400S 2001 User Manual

6-52 CHASSIS
BRAKE FLUID REPLACEMENT
Remove the reservoir cover 1 and reservoir tank mounting
bolt 2.
Remove the reservoir cap and diaphragm.
Replace the brake fluid. ( 6-43)
Specification and classification: DOT 4
Bleed air from the brake system.
( 2-19 and 2-20)
1
2

Suzuki DR-Z400S 2001 Specifications

General

Bore x Stroke	90.0 mm x 62.6 mm
Compression Ratio	11.3:1
Ignition	Electronic ignition (CDI)
Transmission	5-speed constant mesh
Final Drive	Chain
Front Suspension	Telescopic, coil spring, oil damped
Rear Suspension	Link type, coil spring, oil damped
Front Tire	80/100-21
Rear Tire	120/90-18
Seat Height	935 mm (36.8 in)
Engine Type	398cc, 4-stroke, liquid-cooled, DOHC
Front Brakes	Single hydraulic disc
Rear Brakes	Single hydraulic disc
Ground Clearance	300 mm (11.8 in.)
Wheelbase	1, 485 mm (58.5 in)
Fuel Tank Capacity	10.0 L (2.6 US gal.)
Fuel System	Mikuni BSR36, single carburetor
