SPOKE NIPPLE
Check the tension to verify the tightness of the spoke
nipples. The tension of the spokes can be checked by
squeezing the spokes with your fingers. If a spoke nip-
ple is loose, the spoke will bend more than the others.
Retighten the spoke nipples with a spoke nipple
wrench so as all spokes have same tension.
NOTICE
Improperly tightening the spoke nipples can
damage the wheel.
Tighten the spoke nipples less than 1/2 turn at
a time. Inspect the spoke tension and then
retighten the spoke nipple.
HEADLIGHT BEAM ADJUSTMENT
The headlight beam can be adjusted both up and
down or right and left if necessary.
To adjust the beam right and left:
Turn the adjuster screw A clockwise or counterclock-
wise.
To adjust the beam up and down:
Turn the adjuster screw A and B clockwise or coun-
terclockwise.
A: Adjuster screw
B: Adjuster screw
NOTE:
Adjust the headlight beam to the traffic regulations
of your country.
