26
REAR VIEW MIRROR
Install the rear view mirror and tighten lock nuts
securely after positioning them properly.
Rear view mirror lock nut B:
28 N·m (2.8 kgf-m, 20.0 lbf-ft)
A: Rear view mirror
B: Lock nut
C: Lock nut
NOTE:
Set the center line of the rear view mirror stay at
90° from the center line of the motorcycle.
NOTE:
• Align the mirror in the position so as to secure
rear view.
• Do not loosen the lock nut C.
9090°
