7
The certification of vehicle pre-delivery form must
be filled out in duplicate for every motorcycle. Use
of this form is mandatory and serves as pro-
tection for yourself and your customer, as well as
assuring that all necessary assembly and service
functions have been completed.
ASSEMBLY
The photograph shown indicates the parts dismounted
from the motorcycle in addition to the items shown in
the preceding page.
A: Front brake master cylinder
B: Throttle assembly
Right switch
C: Clutch cable
D: Choke cable
Left switch
E: Speedometer drive gearbox
F: Rear turn signal light (Left)
REMOVING THE BRACKET
A: Pad
NOTE:
Put a suitable pad A to prevent the motorcycle
from being damaged.
