COMPONENT PARTS AND WORK TO BE DONE
Under the name of each system or unit, is its exploded view. Work instruction and tightening torque,
lubricating points and locking points, are provided.
Example: Front wheel
1
2
3
4
5
6
7
A
8
B
N•m
Kgf•m
18-28
36-52
1.8-2.8
3.6-5.2
Front axle shaft
Spacer
Dustcover
Washer
Front brake disc
Oil seal
Roller bearing
Spacer
ITEM
9
10
Front tire
Front wheel rim
Speedometer gear driver
Oil seal
HOW TO USE THIS MANUAL
TO LOCATE WHAT YOU ARE LOOKING FOR:
1.The text of this manual is divided into 7 sections.
2.The section titles are listed in the GROUP INDEX.
3.Holding the manual as shown as at the right will allow you to find
the first page of the section easily.
4.The contents are listed on the first page of each section to help
you find the item and page you need.
A
B
Speedometer gear box
Brake disc bolt
Front axle nut
11
12
13
