CHASSIS
5-7
REMOVAL AND DISASSEMBLY
Remove the front wheel (refer to page 5-2).
Remove the two bolts and dismount the front caliper .
Remove the cap bolt and draw out the spacer and absorber
spring.
1
Remove the four bolts and take off the front fender .
Remove the four handlebar holder clamp bolts, take off the
handle bar , then remove the two front absorber cap bolts.
Remove the decoration plate.
Loosen the lower bracket clamp bolts, put down the left and
right front absorbers.
2
3
3
2
