CHASSIS
5-14
Remove the two bolts and take off the dashboard assembly.
Remove the ignition switch cover.
Remove the handlebar holder clamp bolts, take off the
handlebar .
Remove the front absorber cap bolts and steering stem nut,
take off the upper bracket.
Take off the front absorbers.
1
1
Remove the steering stem nut and draw out steering stem.
09940-14911: Steer stem nut wrench
Hold the steering stem by hand to prevent from falling.
CAUTION
Remove the steering stem dust seal and upper bearing outer
race.
