ENGINE
3-2
ENGINE REMOVAL AND INSTALLATION
ENGINE REMOVAL
Before taking the engine out of the frame, wash the engine
with a suitable cleaner. The procedure of engine removal is
sequentially explained in the following steps:
Support the motorcycle with main stand.
Drain the engine oil.
Remove the left and right seat mounting bolts and left rear
shock absorber nut, then take off the seat.
Remove the left and right side cover
Remove the battery lead.
.
Turn off the fuel switch, remove the fuel hose.
Disconnect the fuel gauge coupler.
Take off the fuel tank by removing the mounting bolts .
Take off the clutch cable by removing the clutch lever bolt
2 and adjuster lock nut .
1
3
