Suzuki GN125F - Front Absorber Service

CHASSIS
5-6
FRONT ABSORBER
CONSTRUCTION
B
3
9
10
11
O-ring
Plug
Tube
Oil lock piece
Oil seal
ITEM
N•m
kgf•m
A
4
5
6
1
2
13
Washer
Rebound spring
Ring
Oil seal
Outer tube
7
8
14
A
B
Damper rod
Inner tube
Front axle pinch bolt
Oil seal stopper ring
Seal ring
Damper rod bolt
B
35-55 3.5-5.5
20-26 2.0-2.6
1
2
