ENGINE
3-6
CYLINDER HEAD AND VALVE
When removing cylinder head cover piston must be
at top dead center on compression stroke.
,
REMOVAL
Drain the engine oil, take off the engine. (Refer to page 3-2)
Remove the generator cover cap and valve timing inspect-
ing plug .
Bring the piston to top dead center.
Remove the camshaft chain tensioner .
Loosen the cylinder head cover bolts diagonally.
Remove the cylinder head cover.
Remove the valve inspecting caps .
3
4
Do not remove
1
2
