CHASSIS
5-5
BRAKE DISC
Make sure that the brake disc is clean and free of any
greasy matter.
Install the brake disc, tighten to the brake disc bolts to the
specified torque.
Bend the lock washer to the brake disc bolt.
Front brake disc bolt: 18~28 N•m
FRONT AXLE SHAFT
Install the front wheel and front axle tighten the front axle
nut to the specified torque
,
.
N•mFront axle nut: 36-52
SPEEDOMETER GEAR BOX
99000-25010: Super grease ”A”
Before installing the speedometer gear box, apply Super
Grease A to it, then install it on the wheel.
After installing the front wheel, pump the brake lever
until the pistons push the pads correctly.
WARNING
WARNING
CAUTION
When tightening the front axle, check to be sure that
speedometer gear box is in the position shown.
