CHASSIS
5-4
REASSEMBLY
Reassemble and remount the front wheel in reverse order of
removal. Pay special attention to the following points.
Apply Super Grease ”A” to bearings before reassembly.
99000-25010: Super grease ”A”
The sealed cover of the bearing must face outside.
09924-84521: Bearing installer
a
B
A
Left bearing
Spacer
Right bearing
Removed wheel bearing
LH
RH
Clearance
Install left wheel bearing first, then install the spacer
and right wheel bearing with the special tool and removed
wheel bearings .
2
Apply the Super Grease A to the dust seal lips.
Install the new dust seals using the special tool.
09913-70210 : Bearing installing set (10-75 )Φ
DUST SEAL
WHEEL BEARING
99000-25010 : Super grease ”A”
1
2
3
4
1
2
3
4
