ENGINE
3-3
Remove the generator and gear indication light coupler 5
and .
Disconnect the carburetor balancer pipe by unscrewing
the clamp screws.
Take off the engine sprocket cover
Disconnect the ground wire from the crankcase.
Take off the drive chain by removing the clip .
.
Remove the crankcase breather pipe .
Remove the speedometer cable mounting screw, take off the
speedometer cable assembly .
Loosen the throttle cable adjuster lock nuts, and take off the
throttle cable .
13
12
11
9
10
8
5
6
7
