CHASSIS
5-13
REMOVAL
Disconnect the couplers and lead wires.
Remove the lead wires from the headlight housing.
Remove the two bolts and take off the headlight housing.
Remove the two nuts and take off the turn signal lights, right
and left.
Loosen the lower bracket bolts.
Remove the tachometer cable.
Remove the front wheel. (Refer to page 5-2)
Remove the front absorber. (Refer to page 5-6)
Remove the two screws and take off the headlight.
To Next Page
