CHASSIS
5-8
11F14 010: Front absorber tools-
Invert the absorber and stroke it several times to remove the
oil.
Remove the damper rod bolt by using the special tools
and hexagon wrench.
Remove the oil lock piece and damper rod with rebound
spring.
Separate the inner tube from the outer tube.
Remove the stopper ring.
Remove the oil seal by using the special tool.
The oil seal removed should be replaced with a new
one.
09913-50121: Oil seal remover
