ENGINE
3-15
11F14 018: Valve spring tools-
CYLINDER HEAD COVER ASSEMBLY
REASSEMBLY
Do not let dirt and dust get into the engine.
Install the valve cotters with the special tool.
Clean the cylinder head cover throughly with detergent.
Lubricate the rocker arm shaft with engine oil.
Mount the rocker arm, rocker spring, flexuous washer and
rocker arm to the cylinder head cover.
Tighten the rocker arm shaft set bolts to the specified torque.
Clean up the cylinder head surface.
Reassemble the cylinder head in the reverse order of dis-
assembly, pay attention to the following points:
Install the dowel pins and cylinder head gasket.
1
