FUEL AND LUBRICATION SYSTEM
4-4
REMOVAL AND DISASSEMBLY
Disconnect the carburetor balance pipe .
Remove the carburetor clamp screw .
Remove the throttle cable
Remove the fuel hose
Remove the carburetor.
.
.
Remove the carburetor diaphragm cover.
Remove the spring, diaphragm and piston.
Remove the float chamber body.
4
3
1
2
