CHASSIS
5-20
CALIPER
Disconnect the brake hose from the caliper catch the
brake fluid in a suitable receptacle.
Remove the caliper mounting bolts and then take off the
caliper.
Remove the brake pads.
Place a rag over the piston to prevent popping up. Force out
the piston by using air gun.
Remove the piston, piston boot and piston seal.
Inspect the master cliper bore for any scratches or other
damage.
Do not use high pressure air to prevent piston damage.
INSPECTION
MASTER CLIPER
1
2
Never reuse brake fluid left over from the last servicing
or stored for a long period of time.
Do not operate the brake lever with the pads removed.
REMOVAL
