VL800K5 (’05-MODEL) 14-31
DEALER MODE
The defective function is memorized in the computer. Use the special tool’s coupler to connect to the dealer
mode coupler. The memorized malfunction code is displayed on LCD (DISPLAY) panel. Malfunction means
that the ECM does not receive signal from the devices. These affected devices are indicated in the code
form.
" 09930-82720: Mode select switch
#
Before checking the malfunct on code, do not disconnect the ECM lead wire couplers.
If the couplers from the ECM a e disconnected, the malfunction code memory is erased and the
malfunction code can not be checked.
MALFUNCTION
LCD (DISPLAY)
INDICATION
FI LIGHT INDICATION INDICATION MODE
“NO” C00
FI light turns OFF.
----
“YES”
C**code is indicated from
small numeral to large
one.
For each 2 sec., code is
indicated.

Suzuki Intruder VL800 Specifications

General

Engine Type	4-stroke, liquid-cooled, SOHC, 45-degree V-twin
Displacement	805cc
Bore x Stroke	83.0 mm x 74.4 mm
Compression Ratio	9.4:1
Fuel System	Fuel injection
Ignition	Electronic ignition (Transistorized)
Transmission	5-speed constant mesh
Final Drive	Shaft drive
Front Suspension	Telescopic, coil spring, oil damped
Rear Suspension	Link type, coil spring, oil damped
Front Brakes	Disc brake
Rear Brakes	Drum brake
Front Tire	130/90-16M/C 67H
Rear Tire	170/80-15M/C 77H
Overall Height	1, 105mm (43.5 inches)
Wheelbase	1, 655 mm
Ground Clearance	140mm (5.5 inches)
Seat Height	700 mm (27.6 in)
