VL800K5 (’05-MODEL) 14-133
BRAKE PEDAL INSTALLATION
HANDLEBAR BALANCER
*1
5 mm (0.20 in)
98 mm (3.86 in)
*1 Apply an adhesive agent.
Handlebar
Throttle grip
Handle balancer expander
Handlebar balancer
Screw
Nut
5.5 N·m
(0.5 kgf-m, 4.0 lb-ft)
1 mm (0.04 in): Right side
0 mm (0 in): Left side
