Suzuki Intruder VL800 User Manual

specifications and service data are indicated with an asterisk mark (*).
CONTENTS
SPECIFICATIONS.... ............................................................................... 2
SERVICE DATA ...................................................................................... 3
17
This chapter describes service specifications, service data and servicing p ocedures which
differ from those of the VL800TK6 ('06-MODEL).
*Please refer to the chapter 1 through 16 f r details which are not given in this chapter.
FUEL PUMP AND FUEL LEVEL GAUGE REMOVAL ........................... 13
FUEL PUMP AND FUEL LEVEL GAUGE INSTALLATION .................. 14
FUEL LEVEL METER INSPECTION ..................................................... 14
FUEL LEVEL GAUGE INSPECTION .................................................... 15
CABLE ROUTING ................................................................................. 16
FRONT BRAKE HOSE ROUTING ........................................................ 17
VL800/TK7 (’07-MODEL)
VL800 / TK7 (’07-MODEL) 17- 1
NOTE:*Any differences between the VL800TK6 ('06-MODEL) and VL800/TK7 ('07-MODEL) in

Suzuki Intruder VL800 Specifications

General

Engine Type	4-stroke, liquid-cooled, SOHC, 45-degree V-twin
Displacement	805cc
Bore x Stroke	83.0 mm x 74.4 mm
Compression Ratio	9.4:1
Fuel System	Fuel injection
Ignition	Electronic ignition (Transistorized)
Transmission	5-speed constant mesh
Final Drive	Shaft drive
Front Suspension	Telescopic, coil spring, oil damped
Rear Suspension	Link type, coil spring, oil damped
Front Brakes	Disc brake
Rear Brakes	Drum brake
Front Tire	130/90-16M/C 67H
Rear Tire	170/80-15M/C 77H
Overall Height	1, 105mm (43.5 inches)
Wheelbase	1, 655 mm
Ground Clearance	140mm (5.5 inches)
Seat Height	700 mm (27.6 in)
