14-122 VL800K5 (’05-MODEL)
PAIR (AIR SUPPLY) SYSTEM AND EMISSION CONTROL SYSTEM
INSPECTION
PCV HOSE
• Remove the PCV hose from the crankcase breather cover.
• Inspect the PCV hose for wear or damage.
• If it is worn or damaged, replace the PCV hose with a new
one.
PAIR HOSES
• Inspect the PAIR hoses for wear or damage.
• Inspect the PAIR hoses for secure connection.
PAIR REED VALVE
• Remove the PAIR control solenoid valve. ($14-123)
• Remove the PAIR reed valve.
• Inspect the reed valve for the carbon deposit.
• If the carbon deposit is found in the eed valve, replace the
PAIR reed valve with a new one.
• Install the PAIR reed valve and PAIR reed valve cover as
shown.
• Install the PAIR control solenoid valve. ($14-123)

Suzuki Intruder VL800 Specifications

General

Engine Type	4-stroke, liquid-cooled, SOHC, 45-degree V-twin
Displacement	805cc
Bore x Stroke	83.0 mm x 74.4 mm
Compression Ratio	9.4:1
Fuel System	Fuel injection
Ignition	Electronic ignition (Transistorized)
Transmission	5-speed constant mesh
Final Drive	Shaft drive
Front Suspension	Telescopic, coil spring, oil damped
Rear Suspension	Link type, coil spring, oil damped
Front Brakes	Disc brake
Rear Brakes	Drum brake
Front Tire	130/90-16M/C 67H
Rear Tire	170/80-15M/C 77H
Overall Height	1, 105mm (43.5 inches)
Wheelbase	1, 655 mm
Ground Clearance	140mm (5.5 inches)
Seat Height	700 mm (27.6 in)
