14-36 VL800K5 (’05-MODEL)
NOTE:
The above form is a standard sample. The form should be modified according to condition and characteris-
tics of each market.
VISUAL INSPECTION
• Prior to diagnosis using the mode select switch or SDS, perform the following visual inspections. The rea-
son for visual inspection is that mechanical failures (such as oil leakage) cannot be displayed on the
screen with the use of mode select switch or SDS.
* Engine oil level and leakage. ($2-8)
* Engine coolant level and leakage. ($2-13)
* Fuel level and leakage. ($2-10)
* Clogged air cleaner element. ($2-4
* Battery condition. ($8-31)
* Throttle cable play. ($2-11)
* Vacuum hoses looseness, bend and disconnection.
*Broken fuse.
* Each warning light operation. ($8-21)
* Exhaust gas leakage and noise. ($2-19)
* Each coupler disconnection
* Clogged radiator core. ($6-5)
MOTORCYCLE/ENVIRONMENTAL CONDITION WHEN PROBLEM OCCURS
Environmental condition
Weather
Temperature
Frequency
Fair Cloudy Rain Snow Always Other
Hot Warm Cool Cold ( °F/ °C) Always
Always Sometimes ( times/ day, month) Only once
Under certain condition
Road Urban Suburb Highway Mountainous ( Uphill Downhill)
Tarmacadam Gravel Other
Motorcycle condition
Engine condition Cold Warming up phase Warmed up Always Other at starting
Immediately after start Racing without load Engine speed ( r/min)
Motorcycle con-
dition
During driving: Constant speed Accelerating Decelerating
Right hand corner Left hand corner At stop
Motorcycle speed when problem occurs ( km/h, Mile/h)
Other

Suzuki Intruder VL800 Specifications

General

Engine Type	4-stroke, liquid-cooled, SOHC, 45-degree V-twin
Displacement	805cc
Bore x Stroke	83.0 mm x 74.4 mm
Compression Ratio	9.4:1
Fuel System	Fuel injection
Ignition	Electronic ignition (Transistorized)
Transmission	5-speed constant mesh
Final Drive	Shaft drive
Front Suspension	Telescopic, coil spring, oil damped
Rear Suspension	Link type, coil spring, oil damped
Front Brakes	Disc brake
Rear Brakes	Drum brake
Front Tire	130/90-16M/C 67H
Rear Tire	170/80-15M/C 77H
Overall Height	1, 105mm (43.5 inches)
Wheelbase	1, 655 mm
Ground Clearance	140mm (5.5 inches)
Seat Height	700 mm (27.6 in)
