AMI Oxytrace QED
Program List and Explanations
A-96.250.531 / 300617 85
5.3.2.342 Calendar:
5.3.2.342.1 Start time: The programmed start time is valid for each of the pro-
grammed days. To set the start time see 5.3.2.341, p. 84.
Range: 00:00:00–23:59:59
5.3.2.342.2 Monday: Possible settings, on or off
to
5.3.2.342.8 Sunday: Possible settings, on or off
5.3.2.44 Run Time: see Interval
5.3.2.54 Delay: see Interval
5.3.2.6 Signal Outputs: see Interval
5.3.2.7 Output/Control: see Interval
The relay will be switched via the Profibus input. No further param-
eters are needed.
5.3.4 Input: The functions of the relays and signal outputs can be de-
fined depending on the position of the input contact, i.e. no function,
closed or open.
5.3.4.1 Active: Define when the input should be active:
5.3.4.2 Signal Outputs: Select the operation mode of the signal outputs
when the relay is active:
5.3.2.1 Function = Fieldbus
No: Input is never active.
When closed Input is active if the input relay is closed
When open: Input is active if the input relay is open
Cont.: Signal outputs continue to issue the measured
value.
Hold: Signal outputs issue the last valid measured
value.
Measurement is interrupted. Errors, except fatal
errors, are not issued.
Off: Set to 0 or 4 mA respectively. Errors, except fatal
errors, are not issued.
