AMI Powercon
Operation
5.4. Changing Parameters and values
Changing
parameters
The following example shows how to set the Q-Flow sensor:
Changing
values
1 Select the parameter you want to
change.
2 Press <Enter>
3 Press [ ] or [ ] key to
highlight the required parameter.
4 Press <Enter> to confirm the se-
lection or <Exit> to keep the previ-
ous parameter).
 The selected parameter is
indicated (but not saved yet).
5 Press <Exit>.
 Yes is highlighted.
6 Press <Enter> to save the new pa-
rameter.
 The system reboots, the new
parameter is set.
5.1.1
Sensors
Flow None
Sensor parameters
Quality Assurance
Temp. Compensation
Sensor parameters
Quality Assurance
Temp. Compensation
5.1.1
Sensors
Flow None
Flow
None
Q-Flow
5.1.1
Sensors
Flow Q-Flow
Sensor parameters
Quality Assurance
Temp. Compensation
Sensor parameters
Quality Assurance
Temp. Compensation
5.1.1
Sensors
Flow Q-Flow
No
Save ?
Yes
1 Select the value you want to
change.
2 Press <Enter>.
3 Set required value with [ ] or
[] key.
4 Press <Enter> to confirm the new
value.
5 Press <Exit>.
 Yes is highlighted.
6 Press <Enter> to save the new val-
ue.
5.3.1.1.1
Alarm High 300mS
Alarm Conductivity
Alarm Low 0.000 S
Hysteresis 1.00
S
Delay 5 Sec
5.3.1.1.1
Alarm Conductivity
Alarm Low 0.000
S
Hysteresis 1.00
S
Delay 5 Sec
Alarm High 120 mS
