Swann AMI Powercon - Maintenance and Operation Details

72 A-96.250.341 / 061015
AMI Powercon
Program List and Explanations
3 Maintenance
3.1 Calibration
Follow the commands on the screen. Save the value with the <en-
ter> key.
3.2 Simulation
To simulate a value or a relay state, select the
 alarm relay,
 relay 1 and 2
 signal output 1 and 2
with the [ ] or [ ] key.
Press the <Enter> key.
Change the value or state of the selected item with the [ ] or
[ ] key.
Press the <Enter> key.
 The value is simulated by the relay/signal output.
At the absence of any key activities, the instrument will switch back
to normal mode after 20 min. If you quit the menu, all simulated val-
ues will be reset.
3.3 Set Time
Adjust date and time.
3.3 Quality Assurance
3.4.5 Follow the commands on the screen. Save the value with the
<enter> key.
Alarm Relay:
Open or closed.
Relay 1 and 2:
Open or closed.
Signal Output 1 and 2:
Actual current in mA
Signal Output 3:
Actual current in mA (if option is installed)
