12. BODY COVER
12-4
Body Cover
1. Removal:
y Remove 4 bolts from rear carrier, and then
remove rear carrier.
y Remove the luggage box.
y Remove 4 screws from the two side cover,
and then remove the side cover.
y Remove 1 screw from the front side.
Screws
Bolts
Screws
