Sym Fiddle 50 - Steering Handle

13. STEERING/FRONT WHEEL/SUSPENSION
13-3
Steering Handle
Removal
Remove the front cover.
Remove wire harness band and then remove the
wire harness couplers.
The counter clock revolves speedometer cable
cap nut
Remove 2 cap nuts from meter ASS’Y and then
remove meter ASS’Y.
Remove bolt / nut from head light stay and then
remove the head light.
Band
Meter cable cap nut
Nuts
Bolt/nut
