15. ELECTRICAL EQUIPMENT
15-19
Bulb Replacement
Headlight
Remove head light corrects.
Remove bulb seat and replace the bulb.
Install the all removed parts.
Front winker light
Remove front winker light lens with ”-“screw
driver
Headlight corrects
