15. ELECTRICAL EQUIPMENT
15-20
Replace front winker light bulb.
Install the all removed parts.
Tail light / Brake light / Rear winker light
Remove 2 screws and then remove tail light lens.
.
Replace tail light and brake light bulb.
Install the all removed parts.
Tail light lens screws
This chapter Contents

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Sym Fiddle 50 and is the answer not in the manual?

Sym Fiddle 50 Specifications

General IconGeneral
Displacement49.5 cc
Cooling SystemAir-cooled
Fuel SystemCarburetor
Front SuspensionTelescopic Fork
Front BrakeDisc
Rear BrakeDrum
Fuel Capacity6.5 liters
Dry Weight95 kg
Engine Type4-Stroke
TransmissionCVT
