10. FUEL SYSTEM
10-11
Air Cleaner
Removal/Installation
Remove the EEC hose from the air cleaner set.
Loosen connection hose clamp.
Remove 2 bolts and then remove the air cleaner
set.
Install in the reverse order of removal
procedures.
Install the air cleaner outer case.
Mounting screws X 5
Air cleaner element
This chapter Contents
Mounting bolts X 2
Hose clamp
