Sym Fiddle 50 User Manual

15. ELECTRICAL EQUIPMENT
15-1
Maintenance Information ················ 15-2
Troubleshooting ······························ 15-3
Battery ·············································· 15-4
Charging System ····························· 15-5
Ignition System································ 15-9
Starting System ······························15-12
Oil Level Switch ······························15-15
Fuel Unit ··········································15-16
Switch/Horn·····································15-17
Bulb Replacement ··························15-19
15
Spark Plug
AC. Generator
Fuse Box
Battery
IGN. Coil
Fuel Unit
Main Switch
Reg. Rec. Comp
Right Handle Switch
Start Relay
Horn
Left Handle Switch
Resistor Comp
Winker Relay
CDI Unit
Oil Level Switch
Home page
Contents
Thermo Switch Unit
Power Filter Unit ASS’Y
Thermo Switch

Sym Fiddle 50 Specifications

General

Displacement	49.5 cc
Cooling System	Air-cooled
Fuel System	Carburetor
Front Suspension	Telescopic Fork
Front Brake	Disc
Rear Brake	Drum
Fuel Capacity	6.5 liters
Dry Weight	95 kg
Engine Type	4-Stroke
Transmission	CVT
