10. FUEL SYSTEM
10-5
Carburetor Remove
Remove the luggage box and body cover.
Disconnect the auto by-starter connector.
Loosen draining screw and then drain out fuel
inside the carburetor.
Loosen carburetor upper part and remove
carburetor upper part.
Remove fuel and oil hoses from carburetor.
Remove carburetor mounting bolt and carburetor.
Auto By-Starter
Inspection
Connect resistor meter to the terminals of auto
by-starter, and then measure its resistance.
If the resistance value exceeds specification too
much, it means that the PTC in the auto
by-starter is malfunction. Then, replace the auto
by-starter.
Resistance value: Max. 10Ω (at cold engine)
Caution
If the resistance value exceeds the standard a
little bit, the auto by-starter may still in normal.
However, it is necessary to check other relative
components for damage.
