1. GENERAL INFORMATION
1-15
Lubrication Points
Engine suspension bushing
Seat lock
Rear wheel bearing
Steering shaft bearing
Speedometer gear/ front
wheel bearing
Side stand shaft
Main stand shaft
Throttle cable/
Front & rear brake lever pivot
This chapter Contents

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Sym Fiddle 50 and is the answer not in the manual?

Sym Fiddle 50 Specifications

General IconGeneral
Displacement49.5 cc
Cooling SystemAir-cooled
Fuel SystemCarburetor
Front SuspensionTelescopic Fork
Front BrakeDisc
Rear BrakeDrum
Fuel Capacity6.5 liters
Dry Weight95 kg
Engine Type4-Stroke
TransmissionCVT
