8. FINAL DRIVING MECHANISM
8-2
Maintenance Information
Limited usage of gear oil：gear oil #140
Recommended oil：Bramax serial oil.
Oil quantity：100 c.c. (90 c.c. as replacement)
Special tools:
Inner type bearing puller (SYM-6204020)
Outer type bearing puller (SYM-6204010)
Final shaft oil seal installer (SYM-9125500)
Drive shaft oil seal installer (SYM-9120200)
Bearing driver 6204 (SYM-9110400)
Bearing driver 6201 (SYM-9610001)
Bearing driver 6203/6004UZ (SYM-9620000)
L. crank puller (SYM-1130000-L)
L. crank shaft install bush (SYM-1130010)
Troubleshooting
Trouble Diagnosis
Engine can be started but scooter can not be moved.
1. Damaged drive gear
2. Burnt out or seized drive gear
Noise
1. Seized, worn or damage gear
2. Worn or loose bearing
Gear oil leaks
1. Excessive gear oil.
2. Worn or damage oil seal
This chapter Contents

Sym Fiddle 50 Specifications

General

Displacement	49.5 cc
Cooling System	Air-cooled
Fuel System	Carburetor
Front Suspension	Telescopic Fork
Front Brake	Disc
Rear Brake	Drum
Fuel Capacity	6.5 liters
Dry Weight	95 kg
Engine Type	4-Stroke
Transmission	CVT
