Symbol MC70 - Page 141

Technical Specifications A - 3
Linear 1D Scanner (SE800HP) Specifications
Optical Resolution 0.005 in. minimum element width
Roll +/- 30° from vertical
Pitch Angle +/- 65° from normal
Skew Tolerance +/- 60° from normal
Ambient Light Sunlight: 8,000 ft. candles (86,112 Lux)
Artifical Light: 450 ft. candles (4,844 Lux)
Shock 2,000 +/- 5% G
Scan Rate 50 (+/- 6) scans/sec (bidirectional)
Scan Angle
46.5
o
(typical)
Laser Power 1.0 mW nominal
2D Imager Engine (SE4400) Specifications
Field of View Horizontal - 32.2°
Vertical - 24.5°
Optical Resolution 640 H x 480 V pixels (gray scale)
Roll 360°
Pitch Angle +/- 60° from normal
Skew Tolerance +/- 50° from normal
Ambient Light Total darkness to 9,000 ft. candles (96,900 Lux)
Shock 2,000 +/- 5% G
Focal Distance from Front of Engine Near: 5 inches
Far: 9 inches
Aiming Element (VLD) 650 nm +/- 5 nm
Illumination Element (LED) 635 nm +/- 20 nm
Table A-1 EDA Technical Specifications (Continued)
Item Description
