Symetrix 601 - Page 89

B-7
Rev 2.2, 10/31/94
STEP MRC Key MRC Displays Data to Set/Enter Comments
181 01 device type
182 00 unit/channel
183 1C edit buffer data set
184 page DEFINE SYSEX
BYTES 8-9
185 24 edit buffer 36
186 BYTE send slider setting
187 page LABEL FOR
slr5
188 R O C use sliders 1-4 to set label to "R O
C"
189 page
Set switch 1 to set the mix to 0
190 page SOURCE DEST
OUT#
setup switch 1
191 SOURCE swt1 use button 1 to set source to swt1
192 DEST SYSEX use slider 2 to set DEST to SYSEX
193 OUT# 1 use slider 3 to set OUT# to 1
194 page DEFINE SYSEX
BYTES 2-3
195 F0 SYSEX
196 00 mfrID0
197 00 mfrID1
198 page DEFINE SYSEX
BYTES 4-7
199 5E mfrID2
200 01 device type
201 00 unit/channel
202 1C edit buffer data set
203 page DEFINE SYSEX
BYTES 8-9
204 27 edit buffer 39
205 0 kills wet signal
206 page LABEL FOR
slr5
207 K I L L use sliders 1-4 to set label to "K I
L L"
208 page
Set switch 2 to turn on sine modulation
209 page SOURCE DEST
OUT#
setup switch 2
210 SOURCE swt2 use button 1 to set source to swt2
211 DEST SYSEX use slider 2 to set DEST to SYSEX
212 OUT# 1 use slider 3 to set OUT# to 1
213 page DEFINE SYSEX
BYTES 2-3
214 F0 SYSEX
215 00 mfrID0
216 00 mfrID1
217 page DEFINE SYSEX
BYTES 4-7
