Symetrix 601 - Page 90

B-8
Rev 2.2, 10/31/94
STEP MRC Key MRC Displays Data to Set/Enter Comments
218 5E mfrID2
219 220 device type
221 222 unit/channel
223 1C edit buffer data set
224 page DEFINE SYSEX
BYTES 8-9
225 2A edit buffer 42
226 227 228 = sine
229 page LABEL FOR
swt2
230 S I N E use sliders 1-4 to set label to "S I
N E"
231 page
Set switch 3 to set triangle modulation.
232 page SOURCE DEST
OUT#
setup slider 5
233 SOURCE slr5 use button 1 to set source to slr5
234 DEST SYSEX use slider 2 to set DEST to SYSEX
235 OUT# 236 use slider 3 to set OUT# to 1
237 page DEFINE SYSEX
BYTES 2-3
238 F0 SYSEX
239 240 mfrID0
241 242 mfrID1
243 page DEFINE SYSEX
BYTES 4-7
244 5E mfrID2
245 246 device type
247 248 unit/channel
249 1C edit buffer data set
250 page DEFINE SYSEX
BYTES 8-9
251 2A edit buffer 42
252 7F 7F = triangle
253 page LABEL FOR
swt3
254 T R I use sliders 1-4 to set label to "T R
I"
255 page
Set switch 4 to turn on random modulation
256 page SOURCE DEST
OUT#
setup switch 4
257 SOURCE swt4 use button 1 to set source to swt4
258 DEST SYSEX use slider 2 to set DEST to SYSEX
259 OUT# 1 use slider 3 to set OUT# to 1
260 page DEFINE SYSEX
BYTES 2-3
261 F0 SYSEX
262 00 mfrID0
263 00 mfrID1
