Synology RT1900ac User Manual

18
Chapter 4: Set up Your Wi-Fi Connection
Create WPS Networks (2.4GHz & 5GHz)
WPS (Wi-Fi Protected Setup) is a standard promoted by the Wi-Fi Alliance to simplify Wi-Fi security settings for
users. Though the setup is quick, the WPS network may not be secure. To keep the WPS network safe, you can
use a push button or a PIN code.
Three ways are available to quickly set up a Wi-Fi network via WPS:
By push button
:
1
Go to
Network Center
>
Wireless
>
WPS
, and select
Enable WPS
. Alternatively, press the WPS button on
your Synology Router.
2
Enable the WPS function on your wireless device. Your wireless device and the Synology Router will be paired
up.
By AP PIN code
:
1
Go to
Network Center
>
Wireless
>
WPS
>
Device PIN
>
By AP PIN code
, and click
Enable
to generate an
AP PIN code.
2
Enter the generated PIN code into your wireless device. Your wireless device and the Synology Router will be
paired up.
By client PIN code
:
1
Enter the PIN code of your wireless device at
Network Center
>
Wireless
>
WPS
>
Device PIN
>
By client
PIN code
.
2
Click
Register
. Your wireless device and the Synology Router will be paired up.
Note:
Client iOS devices cannot join a WPS network because iOS does not support WPS.

Synology RT1900ac Specifications

General

VPN support	PPTP, OpenVPN, L2TP/IPSec
Ethernet LAN	No
Port forwarding	Yes
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
VPN tunnels quantity	5
High power	-
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	1300 Mbit/s
Compatible memory cards	SDHC, SDXC
Ethernet LAN (RJ-45) ports	4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	1
Antennas quantity	3
Antenna gain level (max)	4.6 dBi
USB version	3.2 Gen 1 (3.1 Gen 1)
Frequency band	2.4 & 5 GHz
Frequency range	2.4 - 5 GHz
WLAN data transfer rates supported	600, 1300 Mbit/s
Product color	Black
Internal memory	256 MB
Processor cores	2
Processor frequency	1000 MHz
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	5 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
Security algorithms	SNMP, SSH, WEP, WPA, WPA2
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
Power consumption (typical)	10.82 W
Cables included	LAN (RJ-45)

Weight and Dimensions

Depth	206 mm
Width	66 mm
Height	160 mm
Weight	510 g
