330 Synrad Firestar ti-Series operator’s manual
Firestar ti100 general specifications
Table 3-8 Firestar ti100 general specifications
Parameter Firestar ti100
Output Specifications
Wavelength
†
..................................................10.57–10.63 microns
Power Output
1, 2
..........................................100 Watts
Power Stability
3
.............................................± 7%
Mode Quality .................................................M
2
< 1.2
Beam Waist Diameter (at 1/e
2
)
4
....................2.2 ±0.2 mm
Beam Divergence, full angle (at 1/e
2
)
4
..........< 7.0 mrad
Ellipticity .......................................................< 1.2
Polarization ...................................................Linear, vertical
Extinction Ratio ............................................> 100:1
Rise Time ......................................................< 75 µs
Modulation (Optical response) ....................up to 25 kHz
Input Specifications
Power Supply
Voltage ...................................................48 VDC
Maximum Current
5
................................35 A
Command Input Signal
Voltage ...................................................+3.5 to +6.7 VDC
Current ..................................................10 mA @ +6.7 VDC
Frequency
6
..............................................DC–25 kHz
Duty Cycle .............................................0%–100%
Logic Low State (Vmin–Vmax) .............0.0 to +0.8 VDC
Logic High State (Vmin–Vmax) ............+3.5 to +6.7 VDC
Cooling Specifications (Water-cooled)
Maximum Heat Load ....................................1700 Watts
Minimum Flow Rate ......................................1.5–2.0 GPM, < 60 PSI
Coolant Temperature
7
...................................18–22 °C
* Specifications subject to change without notice.
† Typical. Actual wavelength range may vary from 10.2–10.8 µm.
1 This power level is guaranteed for 12 months regardless of operating hours.
2 48 VDC input voltage to obtain guaranteed output power.
3 From cold start (guaranteed).
4 Measured at laser output.
5 Firestar ti-Series lasers have no appreciable in-rush current.
6 Tested at 5 kHz.
7 Water-cooled lasers can be operated at coolant temperatures up to 30 °C (86 °F) in order to reduce problems associated with
condensation; however, this may result in decreased laser performance and/or reduced laser lifetime.
