22.48
21.35
.25
.094
2.905
.010
5.90
4.120
1.125
.563
.500
BEAM EXIT
2.300
.800
.800
POWER
5VDC
ACCESSORY
THAN .19 INTO FA CE PLAT E
6X 8-32 UNC ACCESSORY
MOUNTING HOLES. SCREWS
SHOULD NOT EXTEND MORE
4
C
L
2X
.75
1.00
2.78
C
L
CONTROL I/O
DC POWER
INTERLOCK
(GRN/RED)
TEMP
(GRN/RED)
READY (YEL)
SHUTTER
(BLUE)
LASE
(RED)
22.98
1.500 20.975
.625
.25
20.980
5.62
2.435
4.87
.250
1/4-20 UNC
.261/4-20 UNC
1/4-20 UNC
1
1
2
2
3
3
3
C
L
4
3
2
1
NOTES:
THIS HOLE PATTERN USED WHEN TOP ACCESS FASTENING DESIRED.
THIS HOLE PATTERN USED WHEN BOTTOM ACCESS FASTENING DESIRED.
HARDENED BALL MOUNTING POINT (Ø.250 STEEL BALL).
BEAM PAT H MAY NOT BE CENTERED OR PERPENDICULAR TO FA CEPLAT E APERTURE.
C
DESCRIPTION:
FINISH:
MATERIAL:
REV
ECO
DATE
DESCRIPTION
DB
TOLERANCES UNLESS NOTED:
.
ANGLE = ±
.
.x = ±
.
.xx = ±
.
.xxx = ±
.
PROPRIETARY
THIS DRAWING IS PROPRIETARY TO
SYNRAD INC. AND SHALL NOT BE
USED OR DISCLOSED IN WHOLE
OR IN P A RT WITHOUT WRITTEN
PERMISSION OF SYNRAD INC.
P A RT NUMBER:
DWG/FILE NUMBER:
SHEET
ENG:
DRAWN BY:
DATE:
UNITS:
CATEGORY:
CHECKED BY:
DATE:
SIZE: B
FINISH CLASS:
APPROVED BY:
DATE:
SYNRAD INC.
4600 Campus Place
Mukilteo, WA 98275
Phone: (425)349-3500
Fax: (425)349-3667
OUTLINE & MOUNTING, WATER-COOLED, Ti60/Ti100
10-Mar-09
300-19847-03
1
.
.
.
300-19847-03
of
1
.
D. DUVALL
Inches
.
.
.
DMD
RELEASE TO PRODUCTION
14-May-09
4045
A
ADD NOTE 4, FACE PLAT E INFO
B
DMD
9-Sep-09
4107
UPDATE COOLING FITTINGS LOCATION
C
.
13-Jan-10
4154
