i.1.7Roofunitwithsteelroof

Forunitswithsteelplateroof,thesteelplatesaredelivereduninstalledonaseparatepallet.Donotstepor

walkontheplates.



i.1.8Pre‐assemblystorage

TheAHUmustbeprotectedfromtheweatherandaccidentalimpact.Plasticpackagingmustbe

removed

andtheunitcoveredwithtarpaulinorsimilarmaterials.Inordertominimizecondensation,sufficientair

circulationmustbeensuredbetweenthecoveringandtheunit.

i.1.9Tiltlessthan30˚duringtransportationofthesectionwithheatpump–DVU

Duringtransportation,theunitsection‐DVUmustalways

beintheuprightpositionortiltedlessthan30˚.

Ifitisnecessarytotilttheunitmorethan30˚,thesuctionpipeofthecompressormustpointupwardsto

preventtheescapeofoilfromthecompressorsump. 

i.2.Installation‐mechanical

i.2.1Freeareainfrontofandabovetheunit

Important!Whenpositioningtheunitonthesite,itmustbeensuredthatanareawiththesamewidthas

theunitiskeptfreeforserviceandinspectionandalsoforreplacementoffansandexchanger,ifneeded.

Thewidth

ofthefreeareamustbeatleast900mm.

Important!Forsafeaccesstothecabinetwithelectricalcomponents,ifthecabinetisplacedontopofthe

unit,thefreeareafromtheupperedgeofthecabinettotheceilingmustbeatleast700mm.

i.2.2

Supportingsurface

Thesurfacebeneaththeunitmustbelevel,horizontalandvibration‐free.Thesurfacemustbeableto

withstandtheloadoftheAHU.WeightsofthesectionsarewritteninAnnex2.

Remember!Ductworkmustbesoundinsulatedandmustnotbemounteddirectlyonbeams,trusses

or

othercriticalbuildingparts.

i.2.3Adjustablefeetunderlegsorbaseframeandtransportofsections

Adjustablefeetareprovidedinacartonboxplacedinsidetheunit.Adjustablefeetaredeliveredforindoor

unitsandnotforoutdoorunits.

Sectionscanbetransportedonthesitebyhand

manualforkliftsorsimilar.Theframeprofilesintheedges

ofthesectionshavecarryingcapacityforliftingbythehandmanualforklifts.




