6—2



6.1Baseframelength720–2420[mm]Unitsize10‐40



WidthprofiletypeE

Unitsize Quantity Length[mm]

DV-10 2 870

DV-15 2 1020

DV-20 2 1170

DV-25 2 1320

DV-30 2 1470

DV-40 2 1620



C A

Framelength[mm] Quantity Length[mm] Quantity

700-770 2 520 4

770-920 2 670 4

920-1070 2 820 4

1070-1220 2 970 4

1220-1370 2 1120 4

1370-1520 2 1270 4

1520-1670 2 1420 4

1670-1820 2 1570 4

1820-1970 2 1720 4

1970-2120 2 1870 4

2120-2270 2 2020 4

2270-2420 2 2170 4




