ARES-G2 Getting Started Guide Page 29
Table 4: Peltier Plate Specifications
Table 5: Peltier Plate Cooling Options
*Operating the Peltier Plate at temperatures that are –20 °C or colder depends on maintaining cool water in the circulator reservoir.
Using room temperature water in the reservoir, the Peltier Plate Accessory can hold at –30°C for about 30 minutes, but the Peltier
Plate temperature will drift upwards as the water in the reservoir becomes warmer.
The Peltier Plate may lose temperature control when the coolant reservoir temperature is more than 45°C to 50°C warmer than the
commanded plate temperature.
Temperature Range –40°C to 180°C, depending on circulator fluid
temperature.
Heating Rate up to 30°C/min
Precision +
0.05°C
Stability +
0.1°C
Geometry Compatibility All ARES-G2 upper Cone and Plate geometries (up to 50 mm diameter)
Optional Accessory Solvent Trap
Option Temperature Range
ARES Computer-Controlled Circulator –40°C to 180°C
Peltier Circulator Model 612 –40°C to 160°C
AR Cooled Circulator Model 340 –20°C to 150°C
ARES Peltier Circulator* –30°C to 140°C
