ARES-G2 Getting Started Guide Page 36
Instrument Specifications
The table found below contains the technical specifications for the ARES-G2.
Item/Area Specifications
Test Station Depth 56 cm (22 in.)
Width 46 cm (18 in)
Height 104 cm (39.37 in)
Power Supply Enclosure Depth 48 cm (19 in)
Width 32 cm (12.5 in)
Height 34 cm (13.5 in)
Oven Supply Enclosure Depth 48 cm (19 in)
Width 32 cm (12.5 in)
Height 11 cm (4.5 in)
Environmental Supply Enclosure Depth 48 cm (19 in)
Width 32 cm (12.5 in)
Height 11 cm (4.5 in)
Weight:
Test Station
Power Supply Enclosure
Oven Supply Enclosure
Environmental Supply Enclosure
104.5 kg (< 230 lbs)
18 kg (40 lbs)
6.8 kg (15 lbs)
9.1 kg (20 lbs)
Power:
Test Station
Power Supply Enclosure
Oven Supply Enclosure
Environmental Control Supply Enclo-
sure
from power supply:
90–264 VAC, 16 amps max
180–264 VAC, 47–63 Hz, 13 amp max
90–264 VAC, 47–63 Hz, 13 amp max
Operating Environmental
Conditions
Temperature: 15–30°C
Relative Humidity: 5–80% (non-condensing)
Installation Category II
Pollution Degree 2
Maximum Altitude: 2000 m (6560 ft)
Minimum clearances of six inches from top and all sides, and eight
inches from temperature control options.
TEST STATION
Transducer Force/Torque Rebalance
Minimum Torque in Oscillation 0.05 µN.m
Minimum Torque in Steady Shear 0.1 µN.m
Maximum Torque 200 mN.m
Torque Resolution 1 nM.n
Normal/Axial Force Range 0.001 to 20 N
