13.0.7 Main Menu Structure - page 5
13-1* Comparators 14-23 Typecode Setting 15-04 Overtemps 15-47 Power Card Ordering No 16-01 Reference [Unit] 13-10 Comparator Operand 14-25 Trip Delay at Torque Limit 15-05 Overvolts 15-48 LCP Id No 16-02 Reference [%] 13-11 Comparator Operator 14-26 Trip Delay at Inverter
Fault
15-06 Reset kWh Counter 15-49 SW ID Control Card 16-03 Status Word
13-12 Comparator Value 14-28 Production Settings 15-07 Reset Running Hours
Counter
15-50 SW ID Power Card 16-05 Main Actual Value [%]
13-2* Timers 14-29 Service Code 15-08 Number of Starts 15-51 Adj. Frequency Drive
Serial Number
16-09 Custom Readout
13-20 SL Controller Timer
14-3* Current Limit Ctrl. 15-1* Data Log Settings 15-53 Power Card Serial Num-
ber
16-1* Motor Status
13-4* Logic Rules 14-30 Current Lim Ctrl, Propor-
tional Gain
15-10 Logging Source 15-55 Vendor URL 16-10 Power [kW]
13-40 Logic Rule Boolean 1 14-31 Current Lim Ctrl, Integra-
tion Time
15-11 Logging Interval 15-56 Vendor Name 16-11 Power [hp]
13-41 Logic Rule Operator 1 14-32 Current Lim Ctrl, Filter
Time
15-12 Trigger Event
15-6* Option Ident 16-12 Motor Voltage
13-42 Logic Rule Boolean 2
14-4* Energy Optimizing 15-13 Logging Mode 15-60 Option Mounted 16-13 Frequency
13-43 Logic Rule Operator 2 14-40 VT Level 15-14 Samples Before Trig-
ger
15-61 Option SW Version 16-14 Motor Current
13-44 Logic Rule Boolean 3 14-41 AEO Minimum Magneti-
zation
15-2* Historic Log 15-62 Option Ordering No 16-15 Frequency [%]
13-5* States 14-42 Minimum AEO Fre-
quency
15-20 Historic Log: Event 15-63 Option Serial No 16-16 Torque [Nm]
13-51 SL Controller Event 14-43 Motor Cosphi 15-21 Historic Log: Value 15-70 Option in Slot A 16-17 Speed [RPM] 13-52 SL Controller Action
14-5* Environment 15-22 Historic Log: Time 15-71 Slot A Option SW Version 16-18 Motor Thermal
16-22 Torque [%] 16-66 Digital Output [bin]
18-1* Fire Mode Log 20-14 Maximum Reference/
Feedb.
20-84 On Reference Bandwidth
16-26 Power Filtered [kW] 16-67 Pulse Input #29 [Hz] 18-10 Fire Mode Log: Event
20-2* Feedback/Setpoint 20-9* PID Controller
16-27 Power Filtered [hp] 16-68 Pulse Input #33 [Hz] 18-11 Fire Mode Log: Time 20-20 Feedback Function 20-91 PID Anti Windup
16-3* Drive Status 16-69 Pulse Output #27 [Hz] 18-12 Fire Mode Log: Date
and Time
20-21 Setpoint 1 20-93 PID Proportional Gain
16-30 DC Link Voltage 16-70 Pulse Output #29 [Hz]
18-3* Inputs & Outputs 20-22 Setpoint 2 20-94 PID Integral Time
16-32 Brake Energy /s 16-71 Relay Output [bin] 18-30 Analog Input X42/1 20-23 Setpoint 3 20-95 PID Differentiation Time 16-33 Brake Energy /2 min 16-72 Counter A 18-31 Analog Input X42/3
20-3* Feedb. Adv. Conv. 20-96 PID Diff. Gain Limit
16-34 Heatsink Temp. 16-73 Counter B 18-32 Analog Input X42/5 20-30 Refrigerant
21-** Ext. Closed-loop
16-36 Inv. Nom. Current 16-75 Analog In X30/11 18-33 Analog Out X42/7 [V] 20-31 User Defined Refrigerant
A1
21-0* Ext. CL Autotuning
16-37 Inv. Max. Current 16-76 Analog In X30/12 18-34 Analog Out X42/9 [V] 20-32 User-defined Refrigerant
A2
21-00 Closed-loop Type
